Stainless Steel Fruit Juice Production Line , UHT Yogurt Production Machine

Stainless Steel Fruit Juice Production Line , UHT Yogurt Production Machine

    • Stainless Steel Fruit Juice Production Line , UHT Yogurt Production Machine
    • Stainless Steel Fruit Juice Production Line , UHT Yogurt Production Machine
    • Stainless Steel Fruit Juice Production Line , UHT Yogurt Production Machine
  • Stainless Steel Fruit Juice Production Line , UHT Yogurt Production Machine

    Product Details:

    Place of Origin: China
    Brand Name: Kaiquan
    Certification: ISO .
    Model Number: KQ 500L KQ 5000L

    Payment & Shipping Terms:

    Minimum Order Quantity: One set
    Price: Negotiable
    Packaging Details: Standard Export Wooden Box
    Delivery Time: 10 to 20 days
    Payment Terms: T/T, L/C
    Supply Ability: 20 Set / Month
    Contact Now
    Detailed Product Description
    Name: UHT Milk Processing Equipment Material: Sanitary Stainless Steel 304 / 316
    Flow: 1000L/Hour -28000L /H Application: Milk ,Yogurt And Yogurt Production
    Voltage /hz /phase: Make To Your Order Turn Key Project: Yes
    Packing: Wooden Box ,Wooden Pallet Warranty: Two Year One Year
    Origin: Shanghai China

                  Stainless Steel Fruit Juice Milk Cheese Yogurt Butter UHT Production Line





    1. This production line is used for the production of pasteurized milk,yogurt,lactobacillus drinks,dairy drinks.According to customers' requirement,we can design the capacity of the production line from 2000bph to 36000bph.The complete production line including milk collection system/power reduction system,water treatment system,sugar melting and blending system,filter,degas,homogenization & sterilization,temperature holding,fermentation,CIP washing,filling,coding,packing.

    Optional configuration

    Material:caw milk/goats'milk/yak milk/powder

    Filling type:cup/plastic bottle/carbon etc.

    Coding:laser/ink jet

    Packaging:carton/turnover box .

    Company information



    2. Technical Parameter :



    Name
    Description

    Plate pasteurizer

    SUS304, Q=500L/h, input temperature: 5 ° C, sterilizing temperature: 85 ° C, hold 30s, output temperature: 5 ° C, sterilizing temperature control automatic.

    Emulsify tank

    SUS304, V=0.5m 3 , double layer, heat insulation, thermometer, CIP clearing head, high-speed emulsify head.

    Balance tank

    SUS304, V=0.5m 3 , single layer, CIP clearing head

    Homogenizer

    SUS304, Q=0.5m 3 /h, 30MPa, 5.5kw

    Milk pump

    SUS304, Q=5m 3 /h, H=24m, 1.5kw

    Double tube filter

    SUS304, 150mesh

    Air compressor

    Max pressure: 6.5bar, air displacement, Q=20-25L/min

    Chiller plant

    Cooling water output temperature: 2 ° C, Q=3000L/h

    Frame, pipe and valve

    SUS304

    Plastic bag packing machine

    SUS304, 250ml, 1500bag/h

    boiler



    Shanghai Kaiquan Machine Valve Co., Ltd is a manufacturer specialized in product design,equipment manufacturing,engineering,installation and technical research.Specialized in food & beverage engineering,brewing engineering,biological engineering,and other fields.Years of production experience,advanced manufacturing technology,excellent equipment quality,honest business philosophy,has won many well-known domestic and foreign customers recognition and support.With the efforts of all stuffs,products have been sold nationwide in 30 province,autonomous regions,and exported to the United States,Canada,Brazil,Peru,Russia,Mongolia,Kazakhstan,Uzbekistan,malaysia,Myanmar,Indonesia,Sir lanka,Pakistan,Nigeria,Algeria,Libya,Sudan and other countries and regions.

    Main products:Juice production line,Protein beverage production line,Tea drink production line,Milk yogurt production line,Carbonated beverage production line,Bottled water production line,Water production line,Bagged liquor wine production line,The beer production line,Collagen production line,Production line for Chinese medicine extraction enrichment,Egg processing turnkey project,etc.

    The compony occupies more than 15000m²,we have the ability to undertake large-scale project,from operation of the project to the execution of the latter part of the whole plant to provide rich experience in the design,so that your business detours starting point higher,with professional installation,technical team and service.We can alse provide the beverage industry complete solutions based on customer requirements.
