304 316 316L Stainless Steel Milk Tank , Yogurt Fermentation Tank KQ-3000L KQ-5000L

304 316 316L Stainless Steel Milk Tank , Yogurt Fermentation Tank KQ-3000L KQ-5000L

    • 304 316 316L Stainless Steel Milk Tank , Yogurt Fermentation Tank KQ-3000L KQ-5000L
    • 304 316 316L Stainless Steel Milk Tank , Yogurt Fermentation Tank KQ-3000L KQ-5000L
  • 304 316 316L Stainless Steel Milk Tank , Yogurt Fermentation Tank KQ-3000L KQ-5000L

    Product Details:

    Place of Origin: Wenzhou China
    Brand Name: Brand :Kaiquan
    Certification: ISO ,CE , FDA
    Model Number: KQ -3000L KQ-5000L

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Sets
    Price: Negotiable
    Packaging Details: Standard Export Wooden Box
    Delivery Time: 35 days after get your advance payment
    Payment Terms: T/T, L/C, Western Union, MoneyGram, , D/A, D/P
    Supply Ability: 500 Set / Month
    Contact Now
    Detailed Product Description
    Name: Milk Cooling Tank Material: Sanitary Stainless Steel 304 / 316 / 316L
    Capacity: 500L To 10000L Treatment: Inside Mirror And Outside Polished
    Insulation: Polyurethane Foam 60mm Motor: ABB Or Siemens
    Delivery: 20 Days After Get Your Advace Payment Origin: Shanghai China

                304 316 316L Stainless Steel Dairy Milk Yogurt Mixing Tank (KQ-3000L KQ-5000L)



    1. Introduction of Milk Mixing Tank :


    Capacity: 3000Litres


    Material: Sanitary Stainless Steel 316
    * Type: with Jacket and insulation
    *Internal shell thickness: 4 mm (316)
    * Jacket thickness: 3mm(304)
    *PU insulation wall: 50mm
    * Out shell thickness: 2 mm(304)
    *Appearance:
    Ellipsoidal head top and down
    * Accessories Included:
    (1) Manhole
    (2) Liquid Inlet / Outlet
    (3) Electric Heating Resistance
    (4) Glycerin Inlet /Outlet
    (5) Temperature Gauge
    (6) Electric Motor & Inverter
    (7) High Speed Mixer (1600RPM)
    (8) CIP Auto Cleaning Ball System
    (9) Four Legs
    (10)Electric Control Board
    (11) Level Meter & Digital Level Meter





    2. Technical Parameter :

    Tank Theory Capacity(L) 3200L
    Tank Working Capacity (L) 3000L
    Working Temperature 80℃
    Material Internal : SS.316 4mm,The rest SS.304
    Surface Treatment Inside Mirror & Polished Outside
    Voltage /Hz /Phase Make to your order .
    Feeder (Manway ) 450mm (Can removed easily by Worker .)
    Heating Electric Heating
    Speed of Mixer( Three Blades) and Power of Motor 1600RPM. 4Kw
    Electric Heating Resistance (Can be removed ) 12Kw * 6Pieces = 48KW
    Heating Area(M2) 6
    Manhole Φ450mm
    Glycerin Inlet /Outlet (Clamp Type ) Φ51mm
    Stirrer Type : Based on your order
    Dimension(CM) 1.55*1.55*260 (Included The Motor 25CM )
    Package Wrap with Soft material then put to wooden box .
    Weight (Kgs ) 1500Kg
