1000L 2000L 3000L Liquid Mixing Tank 1000 Gallon Stainless Steel Tank

1000L 2000L 3000L Liquid Mixing Tank 1000 Gallon Stainless Steel Tank

    • 1000L 2000L 3000L Liquid Mixing Tank 1000 Gallon Stainless Steel Tank
    • 1000L 2000L 3000L Liquid Mixing Tank 1000 Gallon Stainless Steel Tank
    • 1000L 2000L 3000L Liquid Mixing Tank 1000 Gallon Stainless Steel Tank
  • 1000L 2000L 3000L Liquid Mixing Tank 1000 Gallon Stainless Steel Tank

    Product Details:

    Place of Origin: Wenzhou China
    Brand Name: Kaiquan
    Certification: ISO ,CE
    Model Number: KQ 1000L KQ2000L KQ3000L

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set
    Price: Negotiable
    Packaging Details: Standard Wooden Box For Export
    Delivery Time: 25 days after get your advance payment
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 500 Sets
    Contact Now
    Detailed Product Description
    Name: 1000L 2000L 3000L 1000 Gallon Stainless Steel Liquid Heating Mixing Tank Material: Stainless Steel 304 / 316 /316L
    Heating: Steam Heating / Electric Heating Capacity: 100L To 3000L
    Speed Of Mixer: 18RPM / 36RPM /72 RPM OEM: Yes
    Packing: Wooden Box

               1000L 2000L 3000L 1000 Gallon Stainless Steel Liquid Heating Mixing Cooling Tank



    1. Introduction of the tank :



    Three-layered heating mixing tank is mainly used for storing, mixing and heating liquid. It's the ideal mixing, heating and cooling equipment for chemical, food and beverage factory and pharmacy industry.

    1. Tank Part

    Capacity: 2000L

    Material: Stainless Steel 304

    * Type: with Jacket and insulation

    * Internal shell thickness: 4 mm

    * Jacket thickness: 3mm

    *PU insulation wall: 50mm

    * Outer shell thickness: 1.5 mm

    * Appearance: Ellipsoidal head top and down

    * Accessories Included:

    (1) Manhole: DN500mm

    (2) Liquid Inlet/Outlet

    (3)Electric Heating Bar

    (4) Mixing System

    (5) Temperature Gauge

    (6) The Electric Motor

    (7) Electric Cabinet

    (8) Syrup Inlet / Outlet

    (9) Auto CIP Cleaning Ball

    (10) Name Plate

    2. Technical Parameter :



    Tank Capacity(L) 2000L
    Material Food Grade Stainless Steel 304
    Speed of Mixer 36r/min.3KW
    Electric heating bars power 72KW, 380V,50HZ,3PHZ
    Heating Area(M2) 7.5
    Material Input/output Φ63.5mm
    Electricity Make to your order .
    Dimension(CM) 160*160*220
    Package Put on wooden pallets then put into a 20 GP container .
    Weight (Kg) 1500

    1000L 2000L 3000L Liquid Mixing Tank 1000 Gallon Stainless Steel Tank
