Durable UHT Milk Processing Equipment KQ 500L KQ 8000L For Milk / Yogurt

Product Details:

Certification:	CE .
Model Number:	KQ 500L KQ 8000L

Payment & Shipping Terms:

Minimum Order Quantity:	One production line
Price:	Negotiable
Packaging Details:	Standard Export Wooden Box
Delivery Time:	10 to 30 days
Payment Terms:	T/T, L/C
Supply Ability:	20 Set / Month

Contact Now

Detailed Product Description

Name:	Pasteurized Milk Processing Line	Material:	Sanitary Stainless Steel 304 / 316 / 316L
Flow:	300L/Hour -15000L /H	Application:	Milk ,Yogurt And Yogurt Production
Turn Key Project:	Yes	Delivery:	30 Days After Get Your Advance Payment
High Light:	milk processing equipment , milk pasteurization machine

UHT Milk And Pasteurized Sterilized Production Line Milk Processing Machines

1. Intruction of milk production line :

Shanghai Kaiquan Machine Valve Co., Ltd., with registered capital of 1 million, target to develop all kinds of food machenes,insist on the policy of "taking the quality as the life ,seeking the development with credit",our cheangeless goal is to satisfy our customers with high quality products,6000 square meters of processing workshop, producing machines over ten of thousands sets annually, passed the CE quality certification. Every machine is processed finely and being sold to Southeast Asia, Europe & America, the Middle East, South America and other overseas markets, with a complete and scientific quality management system, professional sales team, a mature logistics channels, Alchemy will to provide various types of machines,to meet customer needs.

2. Technical Parameter :

UHT Milk And Pasteurized Sterilized Production Line Milk Processing Machines
No.	Name	Main Technology Parameters
1	Milk Receive/Storage and Cream Separator Unit
2	electron pound scale	maximum weighing 500KG
3	milk weighing tank	made of SUS stainless steel, single layer, product feeded in through 40 mesh filter net, CIP cleaning ball
4	milk acceptor	SUS304 stainless steel, single layer, CIP cleaning ball
5	milk pump	SUS304 stainless steel, pump lift 24M, Hard Alloy Mechanical Seal, Inner Shell Bright-Polished
6	twin piping filter	SUS304 stainless steel, two pipes, stainless steel filter element 100 mesh
7	dish separator	auto residue discharge
8	chilling tank	SUS304 stainless steel , alveolate jacket, attached with compressor
9	milk pump	SUS304 stainless steel, pump lift 24M, hard alloy mechanical seal , inner shell bright-polished
10	Preparing Unit
11	blending tank	SUS304 stainless steel, heating insulated, top off-center vertical agitator, conical head, airtight manhole, breather valve, digital readout thermometer, anti-eddy baffle, supporters with adjustable feet
12	milk pump	SUS304 stainless steel, pump lift 24M, hard alloy mechanical seal , inner shell bright-polished
13	mini set of plate-type heat	SUS304 stainless steel, two stages
14	high speed emulsification tank	SUS304 stainless steel, heat insulated, bottom high speed emulsification, digital readout thermometer, supporters with adjustable feet
15	milk pump	SUS304 stainless steel, pump lift 24M, hard slloy mechanical seal, inner shell bright-polished
16	two piping filter	SUS304 stainless steel, stainless steel filter element 100 mesh
17	Sterilizing, homogenizing unit
18	UHT sterilizer	tube type, sterilizing temperature 137℃, holding time 4s, fully automatic control
19	high pressure homogenizer	40MPa,(starting box included)
20	temperature holding	SUS304, holding 300S
21	distributing plate	SUS304, 3 holes
22	Cheese/Butter processing plant
23	bufferying tank	SUS304 stainless steel, heat insulated, top off-center vertical agitator, conical head, airtight manhole, breather valve, digital readout thermometer, anti-eddy baffle, supporters with adjustable feet
24	milk pump	SUS304 stainless steel, pump lift 24M, Hard Alloy mechnical seal inner Shell bright-polished
25	cream seperator
26	bufferying contanier	SUS304, with cover
27	milk pump	SUS304 stainless steel, pump lift 24M, hard alloy mechnical seal, shell bright-polished
28	butter-churner	SUS304, stepless timing
29	cheese vat	SUS304, with heating jacket and insing device
30	pressor	SUS304 6 heads
31	mould	SUS304, 10L, with cover
32	Yogurt fermentation unit
33	fermentation tank	SUS304 stainless steel, heat insulated, top off-center vertical agitator, conical head, airtight manhole, breather valve, digital readout thermometer, anti-eddy baffle, supporter with adjustable feet
34	rotary pump	SUS304 Stainless Steel,Hard alloy Mechnical Seal , Manual steppless shift
35	plate cooler	SUS304, single stage, milk discharge at 4 degree centigrade
36	rotary pump	SUS 304 stainless steel Hard alloy mechnical seal, manual steppless shift
37	Filling Unit
38	higher positation tank	SUS304, stainless steel, heat insulated, top off-center vertical agitator, conical head, airtight manhole, breather valve, digital readout thermometer, anti-eddy baffle, supporters with adjustable feet
39	pasteurized milk filling machine
40	yogurt filling machine
41	CIP system
42	Semi-auto CIP system	Outer coat of SUS304 stainless steel matereial. Inner shell of SUS316. Single cleaning way. Concentrated acid/alkali tank.
43	CIP return pump	Stainless steel 304L, pump lift 24M, hard alloy mechnical seal, inner Shell bright-polished
44	Installation Part	Project installation and commissioning
